Project 2: Assembling Panoramic Images

Jaclyn Beck

Introduction

Panoramic imaging is useful for capturing scenes that are larger than the normal field of view of the camera. A panoramic scene can be assembled by taking multiple pictures of the scene and stitching them together. The more the camera moves, however, the more the outer images must be distorted to stitch the scene together in a planar fashion. The solution to this is to warp each image in the scene to a cylinder, stitch the warped images together, and 'unwrap' the cylinder. This distorts each image slightly but not to the extent that planar stitching would do.

Methods

I used a Canon Powershot SX100 IS, a tripod, and a Kaidan mount to gather my images. I took 18 images by rotating the camera, covering a full 360 degrees. The images were named in numerical order, starting with '1.jpeg' and ending with '18.jpeg'. The first image was copied and the copy was named '19.jpeg', so that the program would append it to the last image in the sequence for me. Each image was then warped using inverse cylindrical warping:

x' = f*tan((x-xCenter)/f) + xCenter;
y' = (y-yCenter)/cos((y-xCenter)/f) + yCenter;

where x and y are coordinates in the warped image and f is the focal length of the camera in pixels. The pixel color of the warped image at coordinates (x,y) is the color of the pixel at (x',y') in the original image.

After each image is warped, I use SIFT to extract feature points from each image. SIFT comes with a Matlab script that lets you call the SIFT program directly from Matlab, so I call the script every time an image is warped. The feature descriptors and locations are saved into two text files, numbered to match the image they describe. My program then iterates through each image, matching its features with the next image in the sequence, and stitches those two images together. I decided to use the same matching function that SIFT uses, namely I decide if something is a match by taking the dot products of one image's descriptors with another image's descriptors and comparing the best two results with each other. I was originally going to use Euclidean distance but this turned out to be far too slow, while SIFT's method was fast and accurate.

To get the average translation vector between one image and another, I used the RANSAC method. Translations between features were randomly selected, and the number of translation vectors that were within two pixels of the original vector were counted as inliers. The largest group of inliers was used and averaged to get the average translation vector from one image to another. After this vector was calculated, the second image was placed on top of the first image, using the vector to translate it to the proper position. The two images were blended together with a simple linear transition between the first image and the second. This group of actions was repeated with each pair of images in the sequence until the final image was stitched into the panorama. I ran this program on both my set of images and the test images.

Finishing Touches and Results

There was a good amount of drift in my set of images and the test images, so the panoramas assembled by my program still needed cropping and adjusting. I cropped both panoramas with GIMP, such that the first image in the panorama was split down the middle (on the left and right side of the panorama) so that the image would be seamless if the ends were joined. I then wrote a function to calculate the slope of the drift and adjust the panorama's y values accordingly. Finally, I cropped each panorama again to cut out the curved edges from the cylindrical warp, so that the images showed no signs of seaming.

Here is the panorama from the test images (click here for larger version):


Here is the panorama from my set of images (click here for larger version):

Click here for interactive viewer.

I think both images turned out very nicely, although there is a mysterious ghost tree on the left of the second panorama, because SIFT had trouble finding feature matches in those images. I think this is because the sun was shining directly into the camera and it was a little bit windy, making the two pictures of the tree just different enough that they couldn't be matched. That being said, the rest of the blending and matching between images looks really good, and the second panorama (from my set of images) is my favorite of the two.

Running my Program

To run my program, you simply need to open Matlab in the folder with my program files and run makePanorama(photos, outputDir, numPhotos), where photos is the directory where the photos are located, outputDir is where you want all of the warped images, descriptor files, and panoramas to go, and numPhotos is the number of photos in the sequence (not counting the duplicated first photo at the end). This will output several temporary panorama images as they are stitched together, but the very last panorama made will be the one you want. You can then crop it in GIMP as described above, save it, and adjust it by running adjustPanorama(filename, outputFilename) in Matlab.
