More About This Textbook
Overview
The challenges of designing, building, and maintaining large-scale, distributed enterprise systems are truly daunting. Written by and for IT professionals, IT Architectures and Middleware, Second Edition, will help you rise above the conflicts of new business objectives, new technologies, and vendor wars, allowing you to think clearly and productively about the particular challenges you face.
This book focuses on the essential principles and priorities of system design and emphasizes the new requirements emerging from the rise of e-commerce and distributed, integrated systems. It offers a concise overview of middleware technology alternatives and distributed systems. Numerous increasingly complex examples are incorporated throughout, and the book concludes with some short case studies.
Topics covered include:
In this new edition, with updates throughout, coverage has been expanded to include:
Editorial Reviews
Booknews
Focuses on the principles and priorities of enterprise systems design, emphasizing the new requirements brought by e-commerce and distributed, integrated systems. Britton, who works for Unisys, discusses middleware technology alternatives, resiliency, performance and scalability, security, systems management, information access and accuracy, and creation of a new presentation layer for existing applications. Annotation c. Book News, Inc., Portland, OR (booknews.com)From The Critics
IT Architecture And Middleware: Strategies For Building Large, Integrated Systems, presents the essential principles and priorities of system design, emphasizing the new requirements brought about by the rise of e-commerce and distributed, integrated systems. IT professional Christ Britton offers a concise overview of middleware technology alternatives and distributed systems as he covers such topics as information access requirements and data consistency, creation of a new presentation layer for existing applications, application integration, and component architectures. Carl Britton's IT Architecture And Middleware is a highly recommended addition to the growing body of information technology literature and IT architecture reference collections.Product Details
Related Subjects
Meet the Author
Chris Britton is an independent consultant, specializing in IT architecture. He has worked in IT for the last twenty-seven years doing a variety of jobs—programming, technical support, system software design, program management, technical consultancy, and even marketing. More recently he has been spending his time developing an IT modeling tool.
Peter Bye has had a long career in IT as a programmer, analyst, and project manager, focusing on telecommunications, transaction processing, and distributed systems. Currently a system architect for Unisys Corporation, his experience includes work in software development centers and field projects around the world. Peter is a contributor to international standards in systems management, the author of a number of papers on middleware and other IT topics, and a frequent speaker at conferences and other events.
Read an Excerpt
All large organizations have complex, heterogeneous IT systems. All of them need to integrate their applications to support faster, more accurate business processes and to provide meaningful, consistent management information. All organizations are struggling to achieve this.
One reason for their struggle is that they are caught in the crossfire of an IT vendor war. In one corner is Microsoft Corporation, whose strength is its consistent technical strategy based on the .NET set of software technologies and the Windows operating system. In the other corner, ranged against Microsoft, is a group that includes IBM Corporation, Sun Microsystems, Oracle Corporation, and BEA Systems. This group is focusing its resources on the Java environment. This is a battle about who will rule over middleware technology, a battle about how to implement distributed systems. Given the importance of the subject matter, it is a battle for the hearts and souls of IT for the next decade. Why? Because all large organizations have complex, heterogeneous IT systems that need to be brought together.
Vendor wars are only part of the problem. Scratch the surface of a large IT department and you will see many camps, for example, workstation/departmental server "decentralizers" and mainframe "centralizers." Look from another angle and you will see two kinds of people—"techies" and "modelers." A techy will start a project by deciding what platform and software to use and will eventually get around to the boring bit, which is writing application code. A modeler will design the application with a modeling tool, generate a few programs and a database, and will eventually confront the (to him or her) trivial question of what platform it will run on. Modeling to a techy seems abstract and disconnected from reality. Technical issues to a modeler are tedious, and surely, soon we will be able to generate the application from the model at the press of a button, won't we? One key to developing large distributed systems is to bring these people together.
Computer professionals generally are comfortable with developing applications on a single platform to a well-defined set of requirements. The reason is that the technology is well understood; the modelers know that what they design can be implemented, and the techies know they can make it work. Large distributed systems are not like that. A system designed without consideration for the distributed implementation will not work. Even worse, it will only become apparent that it doesn't work when scaling up to production capacity starts. To add to our woes, we are now considering integrating multiple systems, each of which was a challenge to develop in the first place, and each of which is changing at a different speed, driven ever faster by the business. The notion of a "well-defined set of requirements" is not realistic; requirements will always be changing.
It is our contention that modelers need to know something about technology, techies need to know something about modeling, and while we are about it, vendors, commentators, consultants, academics, and marketers need to know why their "solutions" aren't quite the panaceas they claim.
This book is about IT architecture. IT architecture provides a framework for discussing implementation design, and it is in these discussions where techies and modelers should meet. Anyone whose roles and responsibilities include IT architect should know everything in this book. (Note we said "know," not "agree with.")
Although IT architects are an important audience for this book, we have tried to write a book for IT management. We have assumed that the IT managers in our readership come fro m an IT background not a business background; this book is not an introduction to IT. So why do IT managers need a book about IT architecture? It is because here so many of their concerns come together—application flexibility, information quality, resiliency, scalability, and so on. One of our aims is to give IT management the knowledge to call the IT architects to account.
This book gives an overview of the whole subject of building and running large distributed systems. It is a deliberate attempt to step above the detail and the in-fighting to examine what is important, what isn't important, and what we need to do differently from the way we did it 10 years ago. Our contention is that the difference between then and now is much more than simply that there are new tools to play with. Building integrated systems is substantially different from building standalone applications, and it affects everything we do in IT.
A major theme of this book is enterprise computing. In the list of terms abused by the industry, "enterprise computing" has to be somewhere near the top. This book takes the view that enterprise computing is about being able to build systems that support the whole enterprise, which in large organizations means many thousands of users. It's obvious that systems that support thousands of users must have resiliency, scalability, security, and manageability as major concerns. The enterprise computing mentality is not prepared to compromise on these objectives. An old mainframe application written in COBOL that gives you resiliency, scalability, security, and manageability is far superior to any implementation that does not.
This is not to say that you cannot build enterprise-capable applications with modern tools, such as Web services. But to succeed you must understand the principles of building large, resilient systems. The principles that served us well for standalone applications do not all apply for distributed systems and vice versa.
Many people in IT find discussions of principles too abstract and dry, so we have tried to enliven the presentation with many examples.
Many organizations today are trying to avoid all these issues by buying third party application packages. This is partially successful. When you buy a package, you buy an IT architecture, albeit only in the context of the package's functionality. If you buy many packages, it is likely that you must lash them together somehow, and for this you need an IT architect. If the packages are from different vendors, integration is a challenge. In this book, we give you the principles that should help in this task, but we have chosen not to address the challenge directly. Because there are so many packages, to do the subject justice would require another book.
This book is not for everyone. You will find this book short on product detail. It does not tell you anything about installation, there are no proper coding examples, there is no survey of products, and there is little in the way of product comparisons. We make no apologies for any of these omissions. There are many books on coding, and product details change so fast the best place for comparisons is on the Internet. This book does not teach application design. There are many books for this as well. But we hope application designers will read this book because the discussion on the principles for building enterprise systems is vital for them also. Finally, this book is not an academic book. It contains little mathematics except for the back-of-the-envelope calculations to illustrate a few points. We offer a practical, wide-ranging discussion for IT professionals to help them understand what is going on so they can pick out the real issues from the imaginary issues and start building complex distributed systems with confidence.
Changes in the second edition
Changes that led to the second edition fall into three categories: new author, new technology, new approaches to design.
First, authorship has now become a team—Peter Bye has joined Chris. Peter brings a long-standing expertise in integration, networking, systems management, and all matters concerned with designing an IT architecture. Although Peter has concentrated on adding to the technical content in the first part of the book, all parts are mulled over by both of us and authorship is shared. Compare the new text with the old and you will notice small changes scattered everywhere. As befits Peter's additional expertise, where there was one chapter on systems management and security, there are now two.
Second, the book has been updated to take into account new technology, in particular Web services, and consequently new ways of thinking about IT architecture, in particular loosely coupled architectures.
Chris was in the final stages of writing the first edition of the book when Microsoft announced .NET and he had no time to digest the merits of the announcement and incorporate it into the text. When Web services moved toward center stage, it became clear that a fundamental driver was a desire for a more loosely coupled architecture or, more specifically, a loosely coupled integration of tightly coupled archipelagos of system. The integrated applications architecture described in the first edition of this book was a quintessentially tightly coupled approach. When many people said that they could never reach enough agreement across an organization to impose a tightly coupled architecture, we could see some truth to these complaints. But loosely coupled integration is impossible without some common standards, and Web services are now providing them.
However, "loosely coupled" is a fuzzy term, easily bandied about by salespeople and consultants, and you can't just apply Web services pixie dust to create loosely coupled integrated applications. One of our aims with this new edition is to identify when loosely coupled works and when it doesn't, and to lay out the advantages and disadvantages of the different approaches to architecture. In consequence, our approach to IT architecture is very flexible and we present a range of architectural options such as middleware bus architectures, hub and spoke architectures, and Web services architectures. The common theme throughout is the notion of service-oriented architectures.
In concrete terms, describing Web services and other new technology has led to one new chapter and substantial changes to three others.
The third major area of change in this book has to do with design. As in the technology chapters, the changes in the design chapters are partly in response to changes in the industry. In particular, we have felt the need to discuss agile approaches to development and how they can cooperate with an architectural approach. But the wider reason for change is that the authors' understanding has developed in the intervening years. In particular, we have been able to describe a lightweight approach to integration design and to provide a better view on how the IT architecture supports business processes. These changes have led to one new chapter and substantial changes to two others.
We have also tidied up some of the material on changing existing systems and in the process eliminated one chapter. Also, two of the earlier chapters that discuss the history of middleware have been merged since some of the technology has sunk in importance.
Of course, with all these changes to the body of the book, we needed to rewrite the first and last chapters.
In spite of all the changes in the IT industry, it is gratifying to observe how much of the book has remained useful. Although there are substantial changes, we have retained the original structure. The first few chapters are about technology; the middle chapters are about using the technology to meet performance, resilience, security, and system management goals; and the last few chapters are about design.
Organization of this book
You can read this book straight through or use it as a reference. This section explains the structure of the book. If you intend to use it for reference and don't intend to read it through first, we encourage you to read at least Chapters 1, 6, 11, and 16.
In addition to introductory and concluding information, the body of the book falls into four main sections:
The thread that holds these topics together is the focus on IT architecture and implementation design.
Introduction
Chapter 1, The Problem, is an introduction to the rest of the book. Using an example, it points out the main concerns of IT architecture.
Middleware technology alternatives
Chapter 2, The Emergence of Standard Middleware, and the following two chapters are a historical survey of middleware technology. Chapter 2 covers remote procedures calls, remote database access, distributed transaction processing, and message-queuing technologies. It ends with a comparison of message queuing and distributed transaction processing.
Chapter 3, Objects, Components, and the Web, is an overview of the concept of object-oriented interfaces and components. The technologies discussed are DCOM, CORBA, COM+, and Enterprise JavaBeans. The impact of the Web is discussed and the chapter ends with an examination of the concept of sessions.
Chapter 4, Web Services, brings the history of middleware up-to-date with an overview of Web services technology, in the context of service and serviceoriented architecture concepts.
IT architecture guidelines and middleware
Chapter 5, A Technical Summary of Middleware, discusses middleware as a whole, beginning with the parts that make up middleware, with an emphasis on Web services. It also looks at vendor architectures, such as Microsoft .NET and Sun's J2EE, and at the issues surrounding middleware interoperability.
Chapter 6, Using Middleware to Build Distributed Applications, takes an application designer's view of middleware. It examines the major questions, what is middleware for and what is the role of middleware in architectural design? This chapter also proposes some basic architectural patterns—middleware bus, hub, and Web services architectures—and discusses the difference between tight and loose coupling of distributed applications.
Distributed systems technology principles
These four chapters examine architecture design for nonfunctional requirements—performance, resiliency, and so on. We believe that the overall architecture of the system can greatly assist in providing good performance, resiliency, and so on. You cannot just rely on faster, more resilient hardware to get you out of any hole you happen to dig yourself into. These chapters explain why and give some solutions to common problems.
Chapter 7, Resiliency, explains the principles of resiliency in distributed systems. There is discussion on how to use backup systems effectively and on how to write applications so as not to lose vital transactions.Chapter 8, Performance and Scalability, explains the principles of performance and scalability in distributed systems. It describes the crucial importance of looking at the network traffic and the distribution of the data.
Chapter 9, Systems Management, deals with the principles of systems management in distributed systems. It discusses what centralized system management tools can and cannot do for you.
Chapter 10, Security, addresses the principles of security in so far as they impact on architectural design. The emphasis in on access control and where to implement it in the system. Web services security standards are explained, especially the differences between Web services security and earlier forms of security.
Distributed systems implementation design
Chapter 11, Application Design and IT Architecture, is about where architectural design belongs in the context of application design. It proposes an approach based on the idea of levels of design where each level includes some analysis to identify and correct flaws in the design. The following two chapters discuss the top levels in more detail. (Detailed design is well covered in many other books.)
Chapter 12, Implementing Business Processes, describes business processes and why they are important to IT architecture. Four large-scale designs for implementing business processes are discussed: Single Centralized server, Multiple Centralized servers, Pass Through, and Copy out/Copy in.
Chapter 13, Integration Design, discusses integration design at the task or dialogue level. A technique called task/message diagrams for highlighting integration design issues is presented, as are some integration design analysis techniques. The chapter ends with a further discussion of differences between loosely coupled and tightly coupled applications.
Chapter 14, Information Access and Information Accuracy, addresses two information topics that are particularly important for large-scale architectural design. (This book does not try to describe all aspects of design, and database design is well covered in many other books.) The information accuracy section is largely about whether to share data between applications or whether to implement some form of controlled data duplication. Retrofitting a data strategy on existing applications is also covered.
Chapter 15, Changing and Integrating Existing Applications, covers creating a new presentation layer for existing applications, integrating existing applications in a service-oriented architecture, and reducing reliance on batch processing.
Conclusion
Chapter 16, Building an IT Architecture, summarizes the contents of the book and reviews a few case studies.
Boxes
Throughout the book you will see references like this: (see the box entitled A box). They refer to the text set apart in screened boxes with a boldface heading. These boxes contain more information about the topic under discussion, perhaps a subject that is more technical than the body of the text or that is an esoteric area we couldn't resist writing about.
The Web site
This book draws on many sources. One problem with the subject, as with most of IT, is the rapidly changing nature of the technology and the ideas behind it. We therefore decided that we would not put a list of sources and pointers to further information in the book itself, as there would no doubt be much additional material available within a few weeks of publication. Indeed, there would probably be new material at the time of publication!
We decided that the best way to provide readers with sources of information, and further case studies and examples, would be to use the Internet. Therefore, this book has an associated Web site, where readers can find additional material: http://eCommunity.unisys.com/Books/ITArchitectures.
On your first visit, you will be asked to complete a simple registration. You will then be forwarded to the appropriate Web page. This Web site will be maintained after publication to keep it up to date.
We would appreciate any comments you may have on the value of this Web site.
Table of Contents
Figures.
Boxes.
Preface.
Acknowledgments.
1. The Problem.
Example: Moving to e-business.
What is IT architecture?
Why is this different from what we did before?
Rewrite or evolve?
Who develops the architecture?
Summary.
2. The Emergence of Standard Middleware.
Early days.
Preliminaries.
Remote procedure calls.
Remote database access.
Distributed transaction processing.
Message queuing.
Message queuing versus distributed transaction processing.
What happened to all this technology?
Summary.
3. Objects, Components, and the Web.
Using object middleware.
Transactional component middleware.
COM_.
EJB.
Final comments on TCM.
Internet Applications.
Summary.
4. Web Services.
Service concepts.
Web services.
Using Web services: A pragmatic approach.
Summary.
5. A Technical Summary of Middleware.
Middleware elements.
The communications link.
The middleware protocol.
The programmatic interface.
Data presentation.
Server control.
Naming and directory services.
Security.
System management.
Comments on Web services.
Vendor architectures.
Vendor platform architectures.
Vendor-distributed architectures.
Using vendor architectures.
Positioning.
Strawman for user target architecture.
Marketing.
Implicit architectures.
Middleware interoperability.
Summary.
6. Using Middleware to Build Distributed Applications.
What is middleware for?
Support for business processes.
Information retrieval.
Collaboration.
Tiers.
The presentation tier.
The processing tier.
The data tier.
Services versus tiers.
Architectural choices.
Middleware bus architectures.
Hub architectures.
Web services architectures.
Loosely coupled versus tightly coupled.
Summary.
7. Resiliency.
Using backup servers.
Detecting failure.
Cleanup work in progress.
Activating the application.
Reprocessing "lost" messages.
Dual active.
Applying resiliency techniques.
System software failure.
Planned downtime.
Application software failure.
Developing a resiliency strategy.
Summary.
8. Performance and Scalability.
The un-slippery slope.
Transaction processing.
Object interfaces.
Transactional component containers.
Two-phase commit.
Message queuing.
Using remote database access for real-time transactions.
Conclusions about real time.
Batch.
Is distribution an alternative?
Load balancing.
Business intelligence systems.
Ad hoc database queries.
Data replication.
Backups and recovery.
Web services.
Design for scalability and performance.
Summary.
9. Systems Management.
Functions and users.
Functional categories.
Inter-relationships and organization.
From silos to distributed environments.
Systems management technology.
Putting it together.
Summary.
10. Security.
What security is needed.
Traditional distributed system security.
Web services security.
Architecture and security.
Summary.
11. Application Design and IT Architecture.
Problems with today's design approaches.
Design up front or as needed?
The role of business rules.
Existing systems.
Reuse.
Silo and monolithic development.
The role of architecture.
Levels of design.
Reconciling design approaches.
Summary.
12. Implementing Business Processes.
What is a process?
Business processes.
Information and processes.
Architecture process patterns.
Clarification and analysis.
Error Handling.
Timing.
Migration.
Flexibility.
Summary.
13. Integration Design.
The context for integration design.
Recovery and long transactions.
How to do integration design.
What makes a good integration design?
Summary.
14. Information Access and Information Accuracy.
Information access.
Basic process information.
Process management.
Process improvement.
Customer view.
Marketing and strategic business analysis.
Summary of requirements for information access.
Information accuracy.
Shared data or controlled duplication.
Shared data.
Controlled duplication.
Hybrid strategy.
Creating consistency in existing databases.
The technical problem.
The data migration problem.
The business process problem.
The information controller.
Summary.
15. Changing and Integrating Applications.
Creating a presentation layer.
Screen-scraping task.
Interface size mismatch.
Turning existing applications into services.
Wrapping.
Building a middle tier.
Business processing change with new interfaces.
Changing the middleware between transaction servers.
Batch.
Summary.
16. Building an IT Architecture.
Case studies.
Case 1: Providing an integration infrastructure.
Case 2: Creating a service-oriented architecture.
Case 3: Developing a new application.
Remarks on common mistakes.
What does the future hold?
The key points to remember.
Middleware technology alternatives.
IT architecture guidelines.
Distributed systems technology principles.
Distributed systems implementation design.
Appendix: Acronyms.
Index.
Preface
All large organizations have complex, heterogeneous IT systems. All of them need to integrate their applications to support faster, more accurate business processes and to provide meaningful, consistent management information. All organizations are struggling to achieve this.
One reason for their struggle is that they are caught in the crossfire of an IT vendor war. In one corner is Microsoft Corporation, whose strength is its consistent technical strategy based on the .NET set of software technologies and the Windows operating system. In the other corner, ranged against Microsoft, is a group that includes IBM Corporation, Sun Microsystems, Oracle Corporation, and BEA Systems. This group is focusing its resources on the Java environment. This is a battle about who will rule over middleware technology, a battle about how to implement distributed systems. Given the importance of the subject matter, it is a battle for the hearts and souls of IT for the next decade. Why? Because all large organizations have complex, heterogeneous IT systems that need to be brought together.
Vendor wars are only part of the problem. Scratch the surface of a large IT department and you will see many camps, for example, workstation/departmental server "decentralizers" and mainframe "centralizers." Look from another angle and you will see two kinds of people—"techies" and "modelers." A techy will start a project by deciding what platform and software to use and will eventually get around to the boring bit, which is writing application code. A modeler will design the application with a modeling tool, generate a few programs and a database, and will eventually confront the (to him or her) trivial question of what platform it will run on. Modeling to a techy seems abstract and disconnected from reality. Technical issues to a modeler are tedious, and surely, soon we will be able to generate the application from the model at the press of a button, won't we? One key to developing large distributed systems is to bring these people together.
Computer professionals generally are comfortable with developing applications on a single platform to a well-defined set of requirements. The reason is that the technology is well understood; the modelers know that what they design can be implemented, and the techies know they can make it work. Large distributed systems are not like that. A system designed without consideration for the distributed implementation will not work. Even worse, it will only become apparent that it doesn't work when scaling up to production capacity starts. To add to our woes, we are now considering integrating multiple systems, each of which was a challenge to develop in the first place, and each of which is changing at a different speed, driven ever faster by the business. The notion of a "well-defined set of requirements" is not realistic; requirements will always be changing.
It is our contention that modelers need to know something about technology, techies need to know something about modeling, and while we are about it, vendors, commentators, consultants, academics, and marketers need to know why their "solutions" aren't quite the panaceas they claim.
This book is about IT architecture. IT architecture provides a framework for discussing implementation design, and it is in these discussions where techies and modelers should meet. Anyone whose roles and responsibilities include IT architect should know everything in this book. (Note we said "know," not "agree with.")
Although IT architects are an important audience for this book, we have tried to write a book for IT management. We have assumed that the IT managers in our readership come fro m an IT background not a business background; this book is not an introduction to IT. So why do IT managers need a book about IT architecture? It is because here so many of their concerns come together—application flexibility, information quality, resiliency, scalability, and so on. One of our aims is to give IT management the knowledge to call the IT architects to account.
This book gives an overview of the whole subject of building and running large distributed systems. It is a deliberate attempt to step above the detail and the in-fighting to examine what is important, what isn't important, and what we need to do differently from the way we did it 10 years ago. Our contention is that the difference between then and now is much more than simply that there are new tools to play with. Building integrated systems is substantially different from building standalone applications, and it affects everything we do in IT.
A major theme of this book is enterprise computing. In the list of terms abused by the industry, "enterprise computing" has to be somewhere near the top. This book takes the view that enterprise computing is about being able to build systems that support the whole enterprise, which in large organizations means many thousands of users. It's obvious that systems that support thousands of users must have resiliency, scalability, security, and manageability as major concerns. The enterprise computing mentality is not prepared to compromise on these objectives. An old mainframe application written in COBOL that gives you resiliency, scalability, security, and manageability is far superior to any implementation that does not.
This is not to say that you cannot build enterprise-capable applications with modern tools, such as Web services. But to succeed you must understand the principles of building large, resilient systems. The principles that served us well for standalone applications do not all apply for distributed systems and vice versa.
Many people in IT find discussions of principles too abstract and dry, so we have tried to enliven the presentation with many examples.
Many organizations today are trying to avoid all these issues by buying third party application packages. This is partially successful. When you buy a package, you buy an IT architecture, albeit only in the context of the package's functionality. If you buy many packages, it is likely that you must lash them together somehow, and for this you need an IT architect. If the packages are from different vendors, integration is a challenge. In this book, we give you the principles that should help in this task, but we have chosen not to address the challenge directly. Because there are so many packages, to do the subject justice would require another book.
This book is not for everyone. You will find this book short on product detail. It does not tell you anything about installation, there are no proper coding examples, there is no survey of products, and there is little in the way of product comparisons. We make no apologies for any of these omissions. There are many books on coding, and product details change so fast the best place for comparisons is on the Internet. This book does not teach application design. There are many books for this as well. But we hope application designers will read this book because the discussion on the principles for building enterprise systems is vital for them also. Finally, this book is not an academic book. It contains little mathematics except for the back-of-the-envelope calculations to illustrate a few points. We offer a practical, wide-ranging discussion for IT professionals to help them understand what is going on so they can pick out the real issues from the imaginary issues and start building complex distributed systems with confidence.
Changes in the second edition
Changes that led to the second edition fall into three categories: new author, new technology, new approaches to design.
First, authorship has now become a team—Peter Bye has joined Chris. Peter brings a long-standing expertise in integration, networking, systems management, and all matters concerned with designing an IT architecture. Although Peter has concentrated on adding to the technical content in the first part of the book, all parts are mulled over by both of us and authorship is shared. Compare the new text with the old and you will notice small changes scattered everywhere. As befits Peter's additional expertise, where there was one chapter on systems management and security, there are now two.
Second, the book has been updated to take into account new technology, in particular Web services, and consequently new ways of thinking about IT architecture, in particular loosely coupled architectures.
Chris was in the final stages of writing the first edition of the book when Microsoft announced .NET and he had no time to digest the merits of the announcement and incorporate it into the text. When Web services moved toward center stage, it became clear that a fundamental driver was a desire for a more loosely coupled architecture or, more specifically, a loosely coupled integration of tightly coupled archipelagos of system. The integrated applications architecture described in the first edition of this book was a quintessentially tightly coupled approach. When many people said that they could never reach enough agreement across an organization to impose a tightly coupled architecture, we could see some truth to these complaints. But loosely coupled integration is impossible without some common standards, and Web services are now providing them.
However, "loosely coupled" is a fuzzy term, easily bandied about by salespeople and consultants, and you can't just apply Web services pixie dust to create loosely coupled integrated applications. One of our aims with this new edition is to identify when loosely coupled works and when it doesn't, and to lay out the advantages and disadvantages of the different approaches to architecture. In consequence, our approach to IT architecture is very flexible and we present a range of architectural options such as middleware bus architectures, hub and spoke architectures, and Web services architectures. The common theme throughout is the notion of service-oriented architectures.
In concrete terms, describing Web services and other new technology has led to one new chapter and substantial changes to three others.
The third major area of change in this book has to do with design. As in the technology chapters, the changes in the design chapters are partly in response to changes in the industry. In particular, we have felt the need to discuss agile approaches to development and how they can cooperate with an architectural approach. But the wider reason for change is that the authors' understanding has developed in the intervening years. In particular, we have been able to describe a lightweight approach to integration design and to provide a better view on how the IT architecture supports business processes. These changes have led to one new chapter and substantial changes to two others.
We have also tidied up some of the material on changing existing systems and in the process eliminated one chapter. Also, two of the earlier chapters that discuss the history of middleware have been merged since some of the technology has sunk in importance.
Of course, with all these changes to the body of the book, we needed to rewrite the first and last chapters.
In spite of all the changes in the IT industry, it is gratifying to observe how much of the book has remained useful. Although there are substantial changes, we have retained the original structure. The first few chapters are about technology; the middle chapters are about using the technology to meet performance, resilience, security, and system management goals; and the last few chapters are about design.
Organization of this book
You can read this book straight through or use it as a reference. This section explains the structure of the book. If you intend to use it for reference and don't intend to read it through first, we encourage you to read at least Chapters 1, 6, 11, and 16.
In addition to introductory and concluding information, the body of the book falls into four main sections:
The thread that holds these topics together is the focus on IT architecture and implementation design.
Introduction
Chapter 1, The Problem, is an introduction to the rest of the book. Using an example, it points out the main concerns of IT architecture.
Middleware technology alternatives
Chapter 2, The Emergence of Standard Middleware, and the following two chapters are a historical survey of middleware technology. Chapter 2 covers remote procedures calls, remote database access, distributed transaction processing, and message-queuing technologies. It ends with a comparison of message queuing and distributed transaction processing.
Chapter 3, Objects, Components, and the Web, is an overview of the concept of object-oriented interfaces and components. The technologies discussed are DCOM, CORBA, COM+, and Enterprise JavaBeans. The impact of the Web is discussed and the chapter ends with an examination of the concept of sessions.
Chapter 4, Web Services, brings the history of middleware up-to-date with an overview of Web services technology, in the context of service and serviceoriented architecture concepts.
IT architecture guidelines and middleware
Chapter 5, A Technical Summary of Middleware, discusses middleware as a whole, beginning with the parts that make up middleware, with an emphasis on Web services. It also looks at vendor architectures, such as Microsoft .NET and Sun's J2EE, and at the issues surrounding middleware interoperability.
Chapter 6, Using Middleware to Build Distributed Applications, takes an application designer's view of middleware. It examines the major questions, what is middleware for and what is the role of middleware in architectural design? This chapter also proposes some basic architectural patterns—middleware bus, hub, and Web services architectures—and discusses the difference between tight and loose coupling of distributed applications.
Distributed systems technology principles
These four chapters examine architecture design for nonfunctional requirements—performance, resiliency, and so on. We believe that the overall architecture of the system can greatly assist in providing good performance, resiliency, and so on. You cannot just rely on faster, more resilient hardware to get you out of any hole you happen to dig yourself into. These chapters explain why and give some solutions to common problems.
Chapter 7, Resiliency, explains the principles of resiliency in distributed systems. There is discussion on how to use backup systems effectively and on how to write applications so as not to lose vital transactions.Chapter 8, Performance and Scalability, explains the principles of performance and scalability in distributed systems. It describes the crucial importance of looking at the network traffic and the distribution of the data.
Chapter 9, Systems Management, deals with the principles of systems management in distributed systems. It discusses what centralized system management tools can and cannot do for you.
Chapter 10, Security, addresses the principles of security in so far as they impact on architectural design. The emphasis in on access control and where to implement it in the system. Web services security standards are explained, especially the differences between Web services security and earlier forms of security.
Distributed systems implementation design
Chapter 11, Application Design and IT Architecture, is about where architectural design belongs in the context of application design. It proposes an approach based on the idea of levels of design where each level includes some analysis to identify and correct flaws in the design. The following two chapters discuss the top levels in more detail. (Detailed design is well covered in many other books.)
Chapter 12, Implementing Business Processes, describes business processes and why they are important to IT architecture. Four large-scale designs for implementing business processes are discussed: Single Centralized server, Multiple Centralized servers, Pass Through, and Copy out/Copy in.
Chapter 13, Integration Design, discusses integration design at the task or dialogue level. A technique called task/message diagrams for highlighting integration design issues is presented, as are some integration design analysis techniques. The chapter ends with a further discussion of differences between loosely coupled and tightly coupled applications.
Chapter 14, Information Access and Information Accuracy, addresses two information topics that are particularly important for large-scale architectural design. (This book does not try to describe all aspects of design, and database design is well covered in many other books.) The information accuracy section is largely about whether to share data between applications or whether to implement some form of controlled data duplication. Retrofitting a data strategy on existing applications is also covered.
Chapter 15, Changing and Integrating Existing Applications, covers creating a new presentation layer for existing applications, integrating existing applications in a service-oriented architecture, and reducing reliance on batch processing.
Conclusion
Chapter 16, Building an IT Architecture, summarizes the contents of the book and reviews a few case studies.
Boxes
Throughout the book you will see references like this: (see the box entitled A box). They refer to the text set apart in screened boxes with a boldface heading. These boxes contain more information about the topic under discussion, perhaps a subject that is more technical than the body of the text or that is an esoteric area we couldn't resist writing about.
The Web site
This book draws on many sources. One problem with the subject, as with most of IT, is the rapidly changing nature of the technology and the ideas behind it. We therefore decided that we would not put a list of sources and pointers to further information in the book itself, as there would no doubt be much additional material available within a few weeks of publication. Indeed, there would probably be new material at the time of publication!
We decided that the best way to provide readers with sources of information, and further case studies and examples, would be to use the Internet. Therefore, this book has an associated Web site, where readers can find additional material: http://eCommunity.unisys.com/Books/ITArchitectures.
On your first visit, you will be asked to complete a simple registration. You will then be forwarded to the appropriate Web page. This Web site will be maintained after publication to keep it up to date.
We would appreciate any comments you may have on the value of this Web site.
Introduction
One reason for this struggle is that they are caught in the crossfire of an IT vendor war. In one corner is Microsoft. The strength of Microsoft is that they have a consistent technical strategy based on .NET and Windows. In the other corner, ranged against Microsoft, is a group that includes IBM, SUN, Oracle and BEA. This group is focusing their resources around the Java environment. This is a battle over who will rule over middleware technology, a battle over how to implement distributed systems. Given the importance of the subject matter, it is a battle for the hearts and souls of IT for the next decade. Why? Because all large organizations have complex, heterogeneous IT systems which need to be brought together.
But vendor wars are only part of the problem. Scratch the surface of a large IT department and you see many camps, in particular, workstation/departmental server "decentralizers" in one camp, mainframe "centralizers" in another. Look from another angle and you will see two kinds of people, "techies" and "modelers." A techy will start a project by deciding what platform and software to use and will eventually get round to the boring bit, which is writing application code. A modeler will design the application with a modeling tool, generate a few programs and a database, and eventually will confront the (to him or her) trivial question, what platform will it run on. Modeling to a techyseems abstract and disconnected from reality. Technical issues to a modeler are tedious, and surely, soon we will be able to generate the application from the model at the press of a button, wont we? One of the keys to developing large distributed systems is to bring these people together.
Computer professionals are in general comfortable with developing applications on a single platform to a well-defined set of requirements. The reason is that the technology is well understood; the modelers know that what they design can be implemented and the techies know they can make it work. Large distributed systems are not like that. A system designed without consideration for the distributed implementation will flat out not work. Even worse, you will only discover that it doesn't work when you start scaling it up to production capacity. To add to our woes, we are now considering integrating multiple systems, each of which was a challenge to develop in the first place, and each of which is changing at a different speed, driven ever faster by the business. The notion of a "well-defined set of requirements" is not realistic; requirements will always be changing.
It is our contention that modelers need to know something about technology, techies need to know something about modeling, and, while we are about it, vendors, commentators, consultants, academics, marketers need to know why their "solutions" aren't quite the panaceas they claim.
This book is about IT Architecture. IT Architecture provides a framework for discussing implementation design, and it is in these discussions where techies and modelers should meet. Anyone with IT Architect in their roles and responsibilities should know everything in this book. (Note we said "know" not "agree with".) They might like to read this book to check up whether our approach to IT Architecture is the same as theirs.
While IT Architects are an important audience for this book, we have tried to write a book for IT management. We have assumed that the IT management in our readership comes from an IT background not a business background; this book is not an introduction to IT. So why do IT management need a book about IT Architecture? It is because it is here that so many of their concerns come together—application flexibility, information quality, resiliency, scalability and so on. One of our aims is to give IT management the knowledge to call the IT Architects to account.
This book attempts to give an overview of the whole subject of building and running large distributed systems. It is a deliberate attempt to step above the detail and the in-fighting to examine what it important, what isn't important, and what we need to do differently from ten years ago. Our contention is that the difference between then and now is much more than simply that there are some new tools to play with. Building integrated systems is substantially different from building standalone applications, and it impacts everything we do in IT.
A major theme of this book is "enterprise computing". In the list of terms abused by the industry, "enterprise computing" has to be somewhere near the top. This book takes the view that enterprise computing is about being able to build systems that support the whole enterprise, which in large organizations means many thousand of users. It's obvious that systems supporting thousands of users must have resiliency, scalability, security and manageability as major concerns. The enterprise computing mentality is about not being prepared to compromise on these objectives. An old mainframe application written in COBOL that gives you resiliency, scalability, security and manageability is far superior to any implementation that does not.
This is not to say that you cannot build enterprise capable application with modern tools, like Web services. But to succeed you must understand the principles of building large, resilient systems. The principles that served us well for standalone applications do not all apply for distributed systems and vice versa. Many people in IT find discussions of principles as too abstract, so we have tried to avoid too dry a presentation style by giving many examples.
Many organizations today are trying to avoid all these issues by buying 3rd party application packages. This is partially successful. When you buy a package, you buy an IT architecture, albeit only in the context of the package functionality. If you buy many packages, it is likely that you must lash them together somehow and for this you need an IT architect. If the packages are from different vendors, integration is a challenge. In this book, we give you the principles that should help in this task, but have chosen not to address the challenge directly. There are so many packages that to do the subject justice would need a book in itself.
This book is not for everyone. If you have no ambitions beyond programming you will find this book short on product detail. It does not tell you anything about installation, there are no proper coding examples, there is no survey of products, and little in the way of product comparisons. This book will probably offend many IT vendors by mentioning their products either not at all or in passing. We have no apologies for any of these omissions. There are many books on coding, and product details change so fast the best place for comparisons is on the Internet. This book does not teach application design. There are many books for this as well. But we hope application designers will read this book because the discussion on the principles for building enterprise systems is vital for them also. Finally this book is not an academic book. There is little mathematics except for the back-of-the-envelope style calculations to illustrate a few points. The aim is for a practical, wide ranging discussion for IT professionals to help them understand what is going on so they can pick out the real issues from the imaginary issues and start building complex distributed systems with confidence.
What has changed in the Second Edition
Changes leading to the second edition fall into three categories.
First authorship has now become a team—Peter Bye has joined Chris. Peter brings a long standing expertise in integration, networking and system management, and in all matters concerned with designing an IT architecture. While Peter has concentrated on adding to the technical content in the first part of the book, all parts are mulled over by both of us and authorship is shared. Compare the new text with the old and you will notice small changes scattered everywhere. As befits his additional expertise, where there was one chapter on system management and security, there are now two.
Second, the book has been updated to take into account new technology, in particular web services, and consequently new ways of thinking about IT architecture, in particular loosely-coupled architectures.
I (Chris) was in the final stages of writing the first edition of the book when Microsoft announced .NET and had no time to digest the merits of the announcement and incorporate it into the text. When Web services became more center stage it became clear that a fundamental driver was a desire for a more loosely-coupled architecture, or more specifically a loosely-coupled integration of tightly-coupled archipelagos of system. The integrated applications architecture described in the first edition of the book was a quintessentially tightly-coupled approach. Many people were saying that they could never reach enough agreement across an organization to impose a tightly-coupled architecture. There is some truth to these complaints, though in my defense loosely-coupled integration is impossible without some common standards and web services are providing them.
However "loosely-coupled" is a fuzzy term, easily bandied about by sales people and consultants, and you can't just apply web services pixie dust to create loosely-coupled integrated applications. One of our aims with this new edition is to identify when loosely-coupled works and when it doesn't, and to lay out the advantages and disadvantages of the different approaches to architecture. In consequence our approach to IT architecture is more flexible and we present a range of architectural options such as middleware bus architectures, hub and spoke architectures and web services architectures. The common theme throughout is the notion of services oriented architectures.
In concrete terms describing web services and other new technology has led to one new chapter and substantial changes to three others.
The third major area of change in this book is in the chapters on design. As in the technology chapters this is partly a response to changes in the industry. In particular we have felt the need to discuss agile approaches to development and how they can cooperate with an architectural approach. But the wider reason for change is that the authors' understanding has developed in the intervening years. In particular we have been able to describe a lightweight approach to integration design and to provide a better view on how the IT architecture supports business processes. These changes have led to one new chapter and substantial changes to two others.
We have also tidied up some of the material on changing existing system and in the process eliminated one chapter. Also two of the earlier history of middleware chapters have been merged as some of the technology has sunk in importance.
With all these changes to the body of the book the first and last chapters have needed a rewrite.
In spite of all the changes in the IT industry, it has been gratifying to observe how much of the book has remained useful. There are a large number of changes in this edition including three new chapters, but they, in the main, provide new content or (we hope) improve the text's clarity. We have retained the original structure. The first few chapters are about technology. The middle chapters are about using the technology to meet performance, resilience, security and system management goals, and the last few chapters are on design.
Finally, we have also providing an appendix about further reading which consist mainly of a pointer to a web site which we plan to keep updated with additional information.
