Cylindrical Coordinates

First, we warped our images into cylindrical coordinates using the following two equations:

theta = arctan(x / f);
h = y / sqrt(x^2 + f^2);

In the above equations, f is the focal length, x is the x coordinate of the 2-d image representation, and y is the y coordinate of the 2-d image representation. This gave us a cylindrical coordinate for each of our x,y positions in our images. After this conversion, we warped our images back into cylindrical image coordinates using the following equations.
new_x = f * theta + x_center;
new_y = f * h + y_center;

In the above equations, the terms x_center and y_center represent the center of the unwrapped cylinder for the cylindrical coordinates. We used these new_x and new_y values to recreate our original images as cylindrical images. Below, we show our original image (left) and its cylindrical image representation (right).
