#include <EnhancedUI.h>
Public Member Functions | |
| void | update () const |
| void | drawBoxAtTilePositionToSize (BWAPI::TilePosition tpos, int width, int height, BWAPI::Color color) |
| int | getMinTileSize (int pixels) |
| int | getMaxTileSize (int pixels) |
| BWAPI::Position | getTilePositionCenter (BWAPI::TilePosition) |
| void | drawRegionBoundingBox (const BWTA::Region *region) |
| void | getRegionBoundingTilePositions (const BWTA::Region *region, BWAPI::TilePosition &topLeftTP, BWAPI::TilePosition &topRightTP, BWAPI::TilePosition &bottomRightTP, BWAPI::TilePosition &bottomLeftTP) |
| void | drawPolygonFromRegion (BWTA::Region *region, BWAPI::Color color) |
| void | drawTilePosition (BWAPI::TilePosition tPos, BWAPI::Color color) |
Private Member Functions | |
| void | drawBases () const |
| void | drawTerrain () const |
Private Attributes | |
| vector< BWAPI::TilePosition > | foundSDTPos |
| vector< BWAPI::TilePosition > | buildSDTPos |
Definition at line 9 of file EnhancedUI.h.
| void EnhancedUI::drawBases | ( | ) | const [private] |
Definition at line 23 of file EnhancedUI.cpp.
References BWAPI::Broodwar.
{
//we will iterate through all the base locations, and draw their outlines.
for(std::set<BWTA::BaseLocation*>::const_iterator i=BWTA::getBaseLocations().begin();i!=BWTA::getBaseLocations().end();i++)
{
BWAPI::TilePosition p=(*i)->getTilePosition();
Position c=(*i)->getPosition();
//draw outline of center location
Broodwar->drawBox(CoordinateType::Map,p.x()*32,p.y()*32,p.x()*32+4*32,p.y()*32+3*32,Colors::Blue,false);
//draw a circle at each mineral patch
for(std::set<BWAPI::Unit*>::const_iterator j=(*i)->getMinerals().begin();j!=(*i)->getMinerals().end();j++)
{
Position q=(*j)->getPosition();
Broodwar->drawCircle(CoordinateType::Map,q.x(),q.y(),30,Colors::Cyan,false);
}
//draw the outlines of vespene geysers
for(std::set<BWAPI::Unit*>::const_iterator j=(*i)->getGeysers().begin();j!=(*i)->getGeysers().end();j++)
{
BWAPI::TilePosition q=(*j)->getTilePosition();
Broodwar->drawBox(CoordinateType::Map,q.x()*32,q.y()*32,q.x()*32+4*32,q.y()*32+2*32,Colors::Orange,false);
}
//if this is an island expansion, draw a yellow circle around the base location
if ((*i)->isIsland())
{
Broodwar->drawCircle(CoordinateType::Map,c.x(),c.y(),80,Colors::Yellow,false);
}
}
}
| void EnhancedUI::drawBoxAtTilePositionToSize | ( | BWAPI::TilePosition | tpos, |
| int | width, | ||
| int | height, | ||
| BWAPI::Color | color | ||
| ) |
Definition at line 94 of file EnhancedUI.cpp.
References BWAPI::Broodwar.
Referenced by TacticalBuildingPlacer::draw(), and EnhancedChokepoint::drawBuildableSupplyDepotForRegion().
{
Broodwar->drawBoxMap(tpos.x() * 32, tpos.y() * 32, ((tpos.x() + width) * 32) - 1,
((tpos.y() + height) * 32) - 1, color);
}
| void EnhancedUI::drawPolygonFromRegion | ( | BWTA::Region * | region, |
| BWAPI::Color | color | ||
| ) |
Definition at line 83 of file EnhancedUI.cpp.
References BWAPI::Broodwar.
{
BWTA::Polygon p = region->getPolygon();
for (int j = 0; j < (int)p.size(); j++) {
Position point1=p[j];
Position point2=p[(j+1) % p.size()];
Broodwar->drawLine(CoordinateType::Map,point1.x(),point1.y(),point2.x(),point2.y(),color);
}
}
| void EnhancedUI::drawRegionBoundingBox | ( | const BWTA::Region * | region | ) |
Definition at line 242 of file EnhancedUI.cpp.
References BWAPI::Broodwar.
{
BWTA::Polygon poly;
BWAPI::Position pLeft, pRight, pTop, pBottom;
poly = region->getPolygon();
pLeft = pRight = pTop = pBottom = (Position) poly[0];
/* get bounds for BWTA region, map top left is (0,0) */
for(int j = 1; j < (int)poly.size(); j++)
{
if(poly[j].x() < pLeft.x()){
pLeft = poly[j];
}
if(poly[j].x() > pRight.x()){
pRight = poly[j];
}
if(poly[j].y() < pTop.y()){
pTop = poly[j];
}
if(poly[j].y() > pBottom.y()){
pBottom = poly[j];
}
}
Broodwar->drawBoxMap(pLeft.x(), pTop.y(), pRight.x(), pBottom.y(), Colors::Purple, false);
}
| void EnhancedUI::drawTerrain | ( | ) | const [private] |
Definition at line 56 of file EnhancedUI.cpp.
References BWAPI::Broodwar.
{
//we will iterate through all the regions and draw the polygon outline of it in green.
for(std::set<BWTA::Region*>::const_iterator r=BWTA::getRegions().begin();r!=BWTA::getRegions().end();r++)
{
BWTA::Polygon p=(*r)->getPolygon();
for(int j=0;j<(int)p.size();j++)
{
Position point1=p[j];
Position point2=p[(j+1) % p.size()];
Broodwar->drawLine(CoordinateType::Map,point1.x(),point1.y(),point2.x(),point2.y(),Colors::Green);
}
}
//we will visualize the chokepoints with yellow lines
for(std::set<BWTA::Region*>::const_iterator r=BWTA::getRegions().begin();r!=BWTA::getRegions().end();r++)
{
for(std::set<BWTA::Chokepoint*>::const_iterator c=(*r)->getChokepoints().begin();c!=(*r)->getChokepoints().end();c++)
{
Position point1=(*c)->getSides().first;
Position point2=(*c)->getSides().second;
Broodwar->drawLine(CoordinateType::Map,point1.x(),point1.y(),point2.x(),point2.y(),Colors::Yellow);
}
}
}
| void EnhancedUI::drawTilePosition | ( | BWAPI::TilePosition | tPos, |
| BWAPI::Color | color | ||
| ) |
Definition at line 17 of file EnhancedUI.cpp.
References BWAPI::Broodwar.
Referenced by EnhancedChokepoint::drawBuildableTilesForRegion(), EnhancedChokepoint::drawTilePositions(), and EnhancedSide::drawTiles().
{
Broodwar->drawBoxMap(tPos.x() * 32, tPos.y() * 32, tPos.x() * 32 + 31,
tPos.y() * 32 + 31, color, false);
}
| int EnhancedUI::getMaxTileSize | ( | int | pixels | ) |
Definition at line 106 of file EnhancedUI.cpp.
{
if(pixels % TILE_SIZE){
return pixels / TILE_SIZE + 1;
}
return pixels / TILE_SIZE;
}
| int EnhancedUI::getMinTileSize | ( | int | pixels | ) |
Definition at line 101 of file EnhancedUI.cpp.
{
return pixels / TILE_SIZE;
}
| void EnhancedUI::getRegionBoundingTilePositions | ( | const BWTA::Region * | region, |
| BWAPI::TilePosition & | topLeftTP, | ||
| BWAPI::TilePosition & | topRightTP, | ||
| BWAPI::TilePosition & | bottomRightTP, | ||
| BWAPI::TilePosition & | bottomLeftTP | ||
| ) |
Definition at line 125 of file EnhancedUI.cpp.
{
BWTA::Polygon poly;
BWAPI::Position pLeft, pRight, pTop, pBottom;
/* tile sizes */
int tsLeft, tsTop, tsRight, tsBottom;
poly = region->getPolygon();
pLeft = pRight = pTop = pBottom = (Position) poly[0];
/* get bounds for BWTA region, map top left is (0,0) */
for(int j = 1; j < (int)poly.size(); j++)
{
if(poly[j].x() < pLeft.x()){
pLeft = poly[j];
}
if(poly[j].x() > pRight.x()){
pRight = poly[j];
}
if(poly[j].y() < pTop.y()){
pTop = poly[j];
}
if(poly[j].y() > pBottom.y()){
pBottom = poly[j];
}
}
/* align to tile sizes */
tsLeft = this->getMaxTileSize(pLeft.x());
tsTop = this->getMaxTileSize(pTop.y());
tsRight = this->getMinTileSize(pRight.x());
tsBottom = this->getMinTileSize(pBottom.y());
/* set tile positions */
topLeftTP.x() = tsLeft;
topLeftTP.y() = tsTop;
topRightTP.x() = tsRight;
topRightTP.y() = tsTop;
bottomRightTP.x() = tsRight;
bottomRightTP.y() = tsBottom;
bottomLeftTP.x() = tsLeft;
bottomLeftTP.y() = tsBottom;
}
| BWAPI::Position EnhancedUI::getTilePositionCenter | ( | BWAPI::TilePosition | tPos | ) |
Definition at line 114 of file EnhancedUI.cpp.
Referenced by EnhancedChokepoint::radialSweepSearch().
{
BWAPI::Position pos;
pos.x() = tPos.x() * 32 + 15;
pos.y() = tPos.y() * 32 + 15;
return pos;
}
| void EnhancedUI::update | ( | ) | const |
Definition at line 10 of file EnhancedUI.cpp.
{
drawTerrain();
drawBases();
// drawProgress();
}
vector<BWAPI::TilePosition> EnhancedUI::buildSDTPos [private] |
Definition at line 46 of file EnhancedUI.h.
vector<BWAPI::TilePosition> EnhancedUI::foundSDTPos [private] |
Definition at line 45 of file EnhancedUI.h.
